FINN-POWER E BRAKE 50-2050 HS TS
- Tonnage: 55
- Bed Length: 81″
- Equipped with Will Upper Clamping
FINN-POWER E BRAKE 50-2050 HS TS
Specifications
Specifications
- Year: 2006
- Capacity (tons): 55 Tons
- Bed length: 81″
- Daylight, q dimension (open height): 25.59″
- Stroke: 11.81″
- Y-axis, return speed: 6.3 inches/second
- X-axis, max. reach back gauge: 22″
- X-axis, repeating accuracy: +/- 0.001″
- X-axis, speed: 13.8 inches/second
- R-axis, max. reach: 6″
- R-axis, accuracy: +/- 0.004″
- R-axis, speed: 3.9 inches/second
- Connected load: 14.7 H.P. (11 Kw)
- Machine length, overall: 130″
- Machine width: 70″
- Machine height, without swivel arm: 99″
- Weight approx. (lbs.): 10,450
- Equipped with Wila Upper Clamping
