Speed-Bend 3760-175 (193T x 12.3’, 6-Axis) Performance Press Brake

  • ERMAK SPEED-BEND 3760-175 (193 Tons x 12.3’)
  • Delem DA66Touch, 2D/3D CNC Control
  • 6 – Axis (Y1, Y2, X, R, Z1, Z2)
  • Heidenhain Linear Glass Scales
  • Mitsubishi MelServo JS Servo Motors & Drives
  • CNC Motorized Wedge Crowning, Anti-Deflection
  • LazerSafe PCSS; Ram-Mounted Laser Safety
  • Precision Tooling Package

Get a Quote

Speed-Bend 3760-175 (193T x 12.3’, 6-Axis) Performance Press Brake

Standard Features

Standard Features

  • ERMAK SPEED-BEND 3760-175 (193 Tons x 12.3’)
  • Delem DA66Touch, 2D/3D CNC Control
    • Profile T ‘Lite’ Desktop Programmming Incl
  • 6 – Axis (Y1, Y2, X, R, Z1, Z2)
  • Heidenhain Linear Glass Scales:
    • o +/-.0002” Resolution
    • o +/-.0004” Repeatability
  • Mitsubishi MelServo JS Servo Motors & Drives:
    • o 31.5” (X-Axis), 9.8” (R-Axis)
    • Belt Driven Z1, Z2

  • CNC Motorized Wedge Crowning, Anti-Deflection
  • LazerSafe PCSS; Ram-Mounted Laser Safety
    • 6mm Mute Point / 24-40 IPM Bending Speeds!
  • Precision Tooling Package:
    • Promecam-Style Quick Release Tool Clamps (American / European; 127mm)
    • Rolleri 0813, 85 Degree Precision Ground & Hardened Gooseneck Punch
    • Rolleri M460, 4-Way V-Die
    • American Riser Block & 4-Way Die Holder

  • Hoerbiger Hydraulic Valve System
  • Siemens Electric System
  • (2) Micro-Adjustable Back-Gauge Fingers
  • (2) Front Sliding Support Arms on THK Ways
  • Photocell (CAT .04) Rear Guard Fiessler / W2000 Sick
  • Side Guards with Safety Switch
  • Double Foot Pedal
  • Dual, 230/460 Voltage, 60V, 3-Phase Electrical
  • RAL 7035, RAL 9007 Colors
  • English Labels & Manuals
  • Mac-Tech Technical Services Machine Commissioning and Operation Training Included (2 Days OnSite)

One Year or 2,080 Hour Parts & Labor (Complex Assemblies) Warranty Included

Delem 66 Touch CNC Controller

Delem 66 Touch CNC Controller

The new generation DA-Touch controls offers an even higher grade of efficiency in programming, operation and control of

today’s press brakes. Ease of use combined with state-of-the-art technology go hand in hand, improving productivity.

The touch screen gives access to the proven Delem user-interface and enables direct navigation between programming and production. Functions are directly located where you need them, offering optimized ergonomics throughout the application.

The DA-66T offers 2D programming that included automatic bend sequence calculation and collision detection. Full 3D machine set-up with multiple tool stations giving true feedback on the product feasibility and handling.

Highly effective control algorithms optimize the machine cycle and minimize set-up time. This makes using press brakes easier, more efficient and more versatile than ever.

The OEM-panel located above the screen, reserved for machine functions and OEM- application switches, is integrated in the design and can be used depending the required application.





DA-66T Features:

      • 2D graphical touch screen programming mode
      • 3D visualization in simulation and production
      • 17” high resolution colour TFT
      • Delem Profile T ‘Lite’ Offline Programming
      • Full Windows application suite
      • Delem Modusys compatibility (module scalability and adaptivity)
      • USB, peripheral interfacing
      • Open System Architecture (3rd Part Software Integration), Optional
      • User specific application support within the controller’s multitasking environment

Specifications

Specifications



ERMAK SPEED-BEND 3760-175
Tonnage 193 US Tons
A Bending Length 148 Inches
B Distance Between Housings 128 Inches
C Stroke 10.8 Inches
D Daylight (Open Height) 21.7 Inches
E Throat Depth 16.1 Inches
F Table Height 35.4 Inches
G Table Width 3.54 Inches
Approach Speed 425 in/minute
Bending Speed 28 in/minute
Return Speed 448 in/minute
Back Gauge Travel (X Axis) 31.5 Inches
Main Motor 20.1 HP
Oil Capacity 79.6 US Gallons
L Machine Length 193 Inches
W Machine Width 85 Inches
H Machine Height 110 Inches
Weight 24,420 lbs
