ERMAKSAN Power-Bend Falcon 4270-500 (14′ x 550 tons)
ERMAKSAN Power-Bend Falcon 4270-500 (14′ x 550 tons)
Description
Description
Brand – 2019 ERMAKSAN
Model – Bend Falcon 4270-500
Type – Press Brakes
Condition – Used – Good
Specifications
Specifications
- BENDING LENGTH: 168.11″
- MAX. POWER: 550 US Tons
- MAX.BENDING CAPACITY (59738 psi): 0.63″
- MAX.BENDING CAPACITY (73974 psi): 0.55″
- MAX.BENDING CAPACITY (81087 psi): 0.55″
- MAX.BENDING CAPACITY (89622 psi): 0.51″
- MAX.BENDING CAPACITY (99580 psi): 0.47″
- AXIS NUMBER OF MACHINE: Y1,Y2,X,R
- FREE DOWN SPEED: 3.15 in/s
- BENDING SPEED: 0.29 in/s
- RETURN BACK SPEED: 2.56 in/s
- STROKE: ( Y1 , Y2 ): 14.76″
- BACK GAUGE STROKE ( X1 AXIS ): 31.50″
- BACK GAUGE STROKE ( R1 AXIS ): 9.84″
- DISTANCE BETWEEN HOUSING: 141.73″
- CROWNING: MOTORIZED
- THROAT DEPTH: 20.08″
- TABLE HEIGHT: 43.31″
- TABLE WIDTH: 9.45″
- DAYLIGHT: 26.57″
- PLANT VOLTAGE: 230 or 460V
- IP: 54
- MAIN MOTOR: 40HP
- BACK GAUGE MOTORS (X,R): 2×4,78Nm
- PLANT TEMPERATURE: 0-50ºC
- MAX. NOISE: 70 dB
- OIL CAPACITY: 132 US Gallons
- MAX. PRESSURE: 3911 psi
- MACHINE LENGTH: 220″
- MACHINE WIDTH: 104″
- MACHINE HEIGHT: 152″
- WEIGHT: 72661lbs
Equipped With
Equipped With
EQUIPPED WITH:
- Delem DA-58T Control
- CNC Crowning
- 4-Axis Backgauge
