ERMAKSAN FIBERMAK GEN-3 G-FORCE
- Sheet: Width 5 ‘
- Sheet Length: 10 ‘
- Wattage: 4000 w
ERMAKSAN FIBERMAK GEN-3 G-FORCE
Specifications
Specifications
- RESONATOR Watt YLR 4000
- POWER RANGE % 10-105
- LASER BEAM QUALITY @ COLLIMATOR mm mrad 1 – 2
- POWER STABILITY % 1 – 3
- PULSE FREQUENCY RANGE kHz 5
- LASER WAVE LENGTH nm 1070 ± 5
- OUTPUT FIBER CORE DIAMETER μm 150
- COOLING WATER FLOW RATE Gallon/Min 2.1
- CUTTING CAPACITY (High Quality)
- MILD STEEL .797”
- STAINLESS STEEL .47”
- ALUMINUM .39”
- BRASS .25”
- COPPER .25”
- MAXIMUM WORKSHEET DIMENSIONS
- 120″ X 60″
- MAXIMUM BURDEN CAPACITY pounds 3307
- MACHINE AXES
- 4-Axes [X, Y, Z, U ]
- Servo Motorized Table
- inch
- 120
- Y AXIS
- ACCELERATIONS
- Servo Motorized Table
- MAXIMUM AXES VELOCITIES
- POSITIONING ACCURACY inch ± 0,001
- SHUTTLE TABLE (Automatic Loading – Unloading Unit)2 ( 35 sec )
- ASSIST GAS
- BECKHOFF CP6242
- 15-inch display 1024 x 768, alphanumeric keyboard, PLC keys on the sides, touch screen keyboard
- AVARAGE POWER CONSUMPTION HP 23
- MACHINE DIMENSIONS ( L x W x H ) inch 362 X 146 X 87
- MACHINE WEIGHT pounds 24,690
Standard Equipment
Standard Equipment
- Sheet Width: 5′
- Sheet Length: 10′
- Wattage: 4000 w
- X-Travel 120 “
- Y-Travel 61 “
- Z-Travel 6 “
- Control CNC (BECKHOFF CNC)
