MDH SERIES ELECTROMECHANICAL TUBE BENDING MACHINE
The AMOB MDH Series Electromechanical Tube Bending Machines provide an efficient and user-friendly solution for tube fabrication, prototyping, and production support applications. Designed to process tubes from 6 mm up to 90 mm OD, the MDH Series combines reliable bending performance with simple operation and fast programming capabilities.
Featuring modern industrial design, ergonomic controls, hydraulic tooling systems, and intuitive software, the MDH Series delivers high-quality bend finishes while reducing setup time and improving overall production efficiency.
MDH SERIES ELECTROMECHANICAL TUBE BENDING MACHINE
Description
Description
The AMOB MDH Series Electromechanical Tube Bending Machines are designed to deliver flexible, precise, and easy-to-operate tube bending solutions for manufacturers entering the world of CNC tube fabrication. Covering capacities from 6 mm up to 90 mm OD, the MDH Series is ideal for production support, prototyping, market validation, and low-to-medium volume manufacturing applications requiring reliable bending performance and fast setup times.
Built with a modern industrial design and ergonomically optimized control system, these machines feature hydraulic mandrel extraction, clamp die, and pressure die systems to produce high-quality bend finishes with excellent consistency. The intuitive software interface allows operators to quickly program complex tube geometries while internally storing up to 3,000 programs for improved workflow efficiency and repeatability.
Available in CN1 and CN3 configurations, the MDH Series offers automatic bending, rotation, and feeding axis control depending on the model selected. Continuous machine monitoring and integrated diagnostics provide real-time operational feedback, warning notifications, and machine status updates to maximize productivity and simplify operation without requiring highly specialized operators.
Spec Sheet
Spec Sheet
SPEC SHEET
- Tube Capacity: 6 mm – 90 mm OD
- Machine Type: Electromechanical Tube Bender
- Control Configurations: CN1 & CN3
- CN1 Automatic Axis: Bending
- CN3 Automatic Axes: Bending, Rotation & Feeding
- Program Storage Capacity: Up to 3,000 Programs
- Interface Type: Interactive Graphic User Interface
- Tooling System: Hydraulic Mandrel Extractor, Clamp Die & Pressure Die
- Machine Design: Ergonomic Industrial Design
- Application Type: Production, Prototyping & Validation
AVAILABLE MODELS
- MDH 60 — Up to 60 mm
- MDH 90 — Up to 90 mm
Equipped With
Equipped With
EQUIPPED WITH
- Electromechanical Tube Bending System
- Interactive Graphic Software Interface
- Hydraulic Mandrel Extractor
- Hydraulic Clamp Die
- Hydraulic Pressure Die
- Ergonomic Control Panel
- Internal Program Storage
- Continuous Machine Monitoring System
- Real-Time Diagnostics & Warning System
Key Features
Key Features
KEY FEATURES
- Processes Tubes From 6 mm to 90 mm OD
- Ideal for Prototyping & Production Support
- User-Friendly CNC Programming Interface
- Stores Up to 3,000 Programs
- Fast Programming of Complex Tube Geometries
- High-Quality Bend Finishes
- Ergonomic & Modern Machine Design
- Reduced Setup & Cycle Times
- Easy Operation Without Specialized Labor
- Continuous Production Capability
- Available in CN1 & CN3 Configurations
- Real-Time Machine Monitoring & Diagnostics
- Reliable & Cost-Effective Tube Bending Solution
