EMOB 2 LR SERIES FULLY ELECTRIC TUBE BENDING MACHINE
The AMOB eMOB LR Series Fully Electric CNC Tube Bending Machines deliver advanced right and left bending technology in a compact, high-speed platform designed for precision tube fabrication. Capable of processing tubes from 5 mm up to 32 mm OD, these machines provide exceptional flexibility, fast cycle times, and reliable repeatability for complex bending applications.
Featuring multi-stack tooling, automatic spring-back compensation, 3D anti-collision simulation, and fully electric servo-controlled operation, the eMOB LR Series offers outstanding productivity, energy efficiency, and value in a compact machine footprint.
EMOB 2 LR SERIES FULLY ELECTRIC TUBE BENDING MACHINE
Description
Description
The AMOB eMOB LR Series Fully Electric CNC Tube Bending Machines combine advanced right and left bending capability with compact machine design and high-speed performance. Engineered to process tubes from 5 mm up to 32 mm OD, these machines support fixed and variable radius bending within the same cycle while allowing complex bend-on-bend parts to be produced with exceptional precision and repeatability.
Designed for maximum efficiency and optimized production cycles, the eMOB LR Series features fully electric servo-controlled operation for faster bending speeds, reduced energy consumption, and lower maintenance requirements. The carriage booster system enables tight-radius bends up to 1D while reducing clamp marks and improving overall bend quality. Advanced CNC controls include automatic spring-back compensation, in-cycle correction, tooling configuration storage, 3D anti-collision simulation, and full axis interpolation for reliable and accurate tube fabrication.
Compact in size yet highly advanced in capability, the eMOB LR Series delivers exceptional performance for manufacturers seeking a fast, flexible, and cost-effective tube bending solution.
Spec Sheet
Spec Sheet
SPEC SHEET
- Tube Capacity: 5 mm – 32 mm OD
- Machine Type: Fully Electric CNC Tube Bender
- Bending Direction: Right & Left In-Cycle Bending
- Bending Capability: Fixed & Variable Radius Bending
- Tool Capacity: Multi-Stack Tooling
- Minimum CLR Capability: Up to 1D Radius
- Axis Control: Fully Interpolated Axes
- Drive System: Independent Servo-Controlled Axes
- Simulation System: 3D Anti-Collision Simulation
- Spring-Back Compensation: Automatic In-Cycle Compensation
AVAILABLE MODELS
- eMOB 16 — Up to 16 mm
- eMOB 32 — Up to 32 mm
Equipped With
Equipped With
EQUIPPED WITH
- Fully Electric CNC Bending System
- Right & Left Bending Capability
- Multi-Stack Tooling Configuration
- Independent Servo Motor Axis Control
- Carriage Booster System
- Automatic Spring-Back Compensation
- In-Cycle Correction System
- Tooling Position & Configuration Storage
- 3D Anti-Collision Simulation
- Electronic Motion Control Monitoring
- Fully Interpolated Axis Control
Key Features
Key Features
KEY FEATURES
- Processes Tubes From 5 mm to 32 mm OD
- Performs Right & Left Bending Within the Same Cycle
- Supports Fixed & Variable Radius Bending
- Bend-on-Bend Capability for Complex Parts
- Achieves Tight Radius Bending Up to 1D
- Compact Machine Design With Advanced Technology
- High-Speed Servo-Controlled Operation
- Reduced Energy Consumption
- Improved Accuracy & Repeatability
- Minimizes Clamp Marks During Bending
- 3D Anti-Collision Simulation for Safer Operation
- Real-Time Machine Monitoring & Diagnostics
- Optimized Production Cycles & Reduced Setup Time
