1999-HACO
HACO

1999 HACO OMATIC 2112 TURRET PUNCH

  • # of Turret Stations: 12
  • Weight: 14.5 T
  • Punching capacity: 22 T
  • Max. sheet thickness: 6 mm

Get a Quote

Category: Tag:

1999 HACO OMATIC 2112 TURRET PUNCH

Standard Equipment

Standard Equipment

  • # of Turret Stations: 12
  • Weight: 14.5 T
  • Punching capacity: 22 T
  • Max. sheet thickness: 6 mm
  • Tool change: automatic
  • Number of indexing stations: all
  • Punching head: hydraulic
  • Max. hit rate for nibbling: 1000 hpm
  • Max. hit rate for marking: 1500 hpm
  • X-axis stroke: 2010 mm
  • Y-axis stroke: 1510 mm
  • Z-axis stroke (punch axis): 37 mm
  • Positioning accuracy X, Y, Z: 0.1 mm
  • CNC control: TPC 69 Graphics
  • Max. sheet weight: 150 kg
  • Power consumption: 25 kW
  • Compressed air: 6 bar
  • Machine weight approx.: 14.5 T

Spec Sheet

Spec Sheet

  • High-speed hydraulic punching head
  • Fully programmable punch axis
  • Tool turret with 12 stations
  • 12 punch and die holders
  • Tool indexing axes( for all tools). – Large brush tables
  • Part chute
  • 6 axis CNC control TPC 69
  • CE optical safety system
  • Scrap suction device
  • 4 vibration dampers
  • Quick toolset for alignment
