RAS 61.31
RAS 61.31
Description
Description
Specifications
Specifications
SPECIFICATIONS
| Max Thickness | 0.1181″ |
| Max Thickness (gauge) | 11 gauge |
| Overall Length | 10′ |
Spec Sheet
Spec Sheet
SPEC SHEET
- Max Thickness 0.0591″
- Max Thickness (gauge) 16 gauge
- Max Bending Length Length 124″ (3150 mm)
- Maximum Sheet Thickness 16 ga/1.5mm CNC
- Folding Beam Adjustment 0” – 0.217”/ 0 – 5.5mm
- Maximum Length 124”/3150mm
- Motor Drive Power Upper Beam 1 hp/.75 kw
- Back gauge Depth 0.236” – 39.4” / 6-1000mm
- Motor Drive Power Folding Beam 1.5 hp/1.1 kw
- Machine Length 170”/4320mm
- Down stroke Speed 2.5”/sec 6mm/sec
- Machine Width 55.1”/1400mm
- Folding Beam Speed 180 degrees/sec
- Machine Height 54.33”/1380mm
- Back gauge Speed (0.4” to 39.3”/8mm – 1000mm) 1.9 sec
- Working Height 33.5”/850mm
- Back gauge Accuracy .004”/.15mm
- Maximum Upper BeamUpstroke 0 – 4.73”/ 0 – 120mm
- Machine Weight 5,500 lbs.
- Dimensions Approx. Shipping Dimensions: 175″ L x 64″ W x 56″ H
- Weight: 5,500
