HYD-MECH V-18A
HYD-MECH V-18A
Description
Description
Specifications
Specifications
Specifications
| Throat | 18″ |
| Work Height | 38″ |
| Power | 10 hp |
| Blade Width | 1.25″ |
| Blade Length | 198″ |
| FPM | 1 |
| Dimensions | 101″ x 145″ x 110″ |
| Weight | 7,500 |
Equipped With
Equipped With
Equipped With
- 2 Transfer Tables
- Hydraulic Tilt
- Hydraulic Blade Tension
- Hydraulic Blade Guide
- Auto Infeed
- Hydraulic Digital Control
Spec Sheet
Spec Sheet
Spec Sheet
- Capacity: 18.5″ X 20.5″
- Capacity At 45 Degrees: 14.5″ x 18″
- Capacity Round at 45 Degrees: 13″
- Head Tilts / Miters : 45 degrees either direction
- Blade Speeds:65 to 385 FPM
- Blade Dimensions: 1.25″ x 14′ 11″
- Head Feed Rate: 0-15 IPM
- Feed Pressure: 0 to 300 psi
- Infeed Table: 26″ x 93″
- Blade Drive Motor: 5 HP
- Hydraulic Drive Motor: 2 HP
- Weight: 8,000 lbs
- Dimensions: L x 102″; W x 117″
- Hydraulic Oil Capacity: 17 gallons
- Power: 208 V 60 Hz 3 phase
