ERBEND MFC 3230
ERBEND MFC 3230
Description
Description
Specifications
Specifications
SPECIFICATIONS
| Max Thickness | 0.059″ |
| Overall Length | 10.5′ |
| Dimensions | 53″ x 165″ x 66.9″ |
| Weight | 4739 lbs |
| Control | CNC (Erfold |
Spec Sheet
Spec Sheet
SPEC SHEET
-
Model: MFC 3215
-
Maximum sheet length: 10.49 ft (3220 mm)
-
Maximum thickness (full length): 16 gauge steel
-
Material capacity:
-
Mild steel: 16g
-
Stainless steel: 19g
-
Aluminum: 0.10”
-
-
Clamping beam (Z Axis):
-
Opening height (no tools): 4.72 in (120 mm)
-
Geometry: 35°
-
Drive power: 1 hp (750 W)
-
-
Folding beam (Y Axis):
-
Drive power: 2 hp (1500 W)
-
Folding angle: 0–135°
-
-
Folding beam adjustment (A Axis): height 1.38 in (35 mm)
-
Back gauge system (X Axis):
-
Drive power: 0.5 hp (400 W)
-
Min/max gauging: 0.024–29.53 in (6–750 mm)
-
-
Dimensions (WxLxH): 53.15” x 165.35” x 66.93”
-
Weight: 4,739 lbs
