Videos Coil Punching
Coil Punching
Description
Description
A new perspective for metal profile fabricators. Punching directly from the coil is possible to produce hole patterns in a simple process. The PRR10 Coil Punching Line by Mac-Tech comes equipped with uncoiler, straightening unit, rotary press with indexing up to 10 tools, cross-cutting guillotine and sheet receiving table.
The rotary servo press can punch up to 10 different tools at a running speed of 1 second. All axes are driven by servo motors to ensure accuracy and speed in all operations. The press performs with a force of 20 tons, which allows the execution of various cutting formats.
ElitePunch software is the revolutionary application where you can import CAD files and process the data combining ease of use and fast machine setup: Step 1. Open file in .dxf format. Step 2. Identify holes and positions. Step 3. Send to the machine via FTP protocol after checking the feasibility of the data. Step 4. Start production.
The software has been specifically developed to also be used via the touch screen and is suitable for installation in the workshop on board the machine.
Specs
Specs
Max Thickness: 4mm
Max Coil Wide: 150 a 750mm
Straightening rolls: 9
Diameter straightener rollers: 125mm
Feeder Speed: 30m/min
Press Speed: 500mm/s
Punching cycle time: 1 second
Speed Orientation: 360°/s
Force of punching: 20 tons
